NHXCH FE180 E90
CABLE STANDARD:
DIN VDE 0266
CABLE STRUCTURE :
- Conductor: CU EN 60228 CLASS 1-2
- 1zole1: MİKA BANT
- Isolated2: Cross-Linked Halogen-Free Polymer
- Fill: LSZH
- Screen: Copper Wire+Tape
- Sheath: LSZH
USAGE:
It is more suitable to be used in environments where there is a possibility of fire (hospital, school, workplace, shopping mall, etc.). It should be preferred at important points to work in case of fire (elevator, fire extinguishing system, etc.). It can be used in dry environments, under plaster and on pans. In the use of pans, care should be taken that the pan is not shared. Special fire resistant pans should be preferred. Not suitable for direct underwater use. Channel should be used for underground use. In addition to the features of the NHXH FE180 series; Thanks to the load discharge that will occur on the copper screen it has, it ensures the protection of the conductivity of the cable at rising temperatures. Insulation resistance is 180 minutes and short circuit resistance is 90 minutes.
Low Voltage Cables, Power Transmission Cables
