General Details
| temperature range | constant: -20 °C… +60 °C active: 0 °C… +50 °C |
| Bending radius min. | constant: min. 4xD active: min. 8xD |
| Tensile strength max. | 110 N |
| Crush resistance min. | 1000 N/10cm |
| Impact resistance min. | 10 blows |
| Conductor resistance max. | 85Ω/km |
| Resistance imbalance max. | 2% |
| Insulation resistance min. | 5000MΩx m |
| capacitance nom. | 50pF/m |
| Capacity imbalance max. | 1600pF/km |
| characteristic impedance | 100 ± 5 Ω @100MHz |
| Propagation speed | 67-69% |
| Propagation delay max. | 537 ns/100m |
| Signal delay max. | 45 ns/100m |
| Test voltage | 1000 V |
| Operating voltage max. | 72 V |
| TCL min. | “Level 2” |
| Coupling attenuation | “Type III” |
| Transfer impedance | “Class 2” |
| Segregation class | “b” EN 50174-2 |
Usage areas
It is a data cable designed for analog and digital signal transmission in audio, video and data applications supporting 250MHz, 1.0Gbit/s 1Gigabit Ethernet in information transmission systems. It meets the structured cabling systems standards, ANSI EIA/TIA 568, ISO/IEC 11801 and EN 50173 Class E class specifications.
IEEE 802.3: 10Base-T; 100Base-T; 1000Base-T; 10GBase-T
IEEE 802.5 16MB; ISDN; TPDDI; ATM
Power over Ethernet (PoE) / PoE+
Cable Structure
| Conductive | Electrolytic copper wire, Ø 23AWG |
| Insulation | Physically foamed PE, conforming to TIA 568 insulation color coding, 70°C, EN 50290-2-23 |
| Cross Separator | PE |
| Sheath | LSZH/LS0H – RAL 1018 Yellow, Ø 6.0mm 70°C, EN 50290-2-27 PVC – RAL 7001 Grey, Ø 6.0mm TM51 70°C, EN 50290-2-22 PE – RAL 9011 Black, Ø 6.0mm 80°C, EN 50290-2-24 |
